Developed for trailers up to 671 ft³ arktik 2500US you can store your beverages and food at temperatures between 32 °F and 50 °F.
Technical Data 2500US
Refrigerated trailer internal temperature
TA=35,6°F [2°C]
Supply voltage
115 V / 1 ~ Phase
Frequency
60 Hz
Refrigeration capacity
7240 BTU/h [2120 W]
Power consumption
964 W
Current consumption LRA
63 A
Current consumption FLA
15 A
Defrost
Automatic hot gas defrost
Evaporator air flow
650 cfm [1100m³ /h]
Condenser air flow
650 cfm [1100m³ /h]
Protection class, mounting side
IP54
Refrigerant (Chlorine: zero-non ozone depleting)
R134a
Refrigerant quantity
1,33 lbs [0,6 kg]
Maximum operating temperature
104°F [40°C]
Weight
122 Ibs [75 kg
Colour
RAL 9010
Refrigeration capacity is based on the following operating conditions: outside temperature 86°F, RH 50 %. We recommend an insulation with a R-value 25 and higher.
-
3 months Labor warranty
-
15 Months Parts Warranty
-
Spare Parts readily available in the US
